Parts |
Solder |
||||
|
Player 2 - Button 1 |
A |
O |
O |
1 |
Player 1 - Button 1 |
|
Player 2 - Button 2 |
B |
O |
O |
2 |
Player 1 - Button 2 |
|
Player 2 - Right |
C |
O |
O |
3 |
Player 1 - Right |
|
Player 2 - Left |
D |
O |
O |
4 |
Player 1 - Left |
|
Player 2 - Down |
E |
O |
O |
5 |
Player 1 - Down |
|
Player 2 - Up |
F |
O |
O |
6 |
Player 1 - Up |
|
Start 2 |
G |
O |
O |
7 |
Start 1 |
|
Coin 2 ? |
H |
O |
O |
8 |
Coin 1 |
|
I |
O |
O |
9 |
||
|
J |
O |
O |
10 |
||
|
Sync |
K |
O |
O |
11 |
Blue |
|
Green |
L |
O |
O |
12 |
Red |
|
M |
O |
O |
13 |
||
|
Speaker + |
N |
O |
O |
14 |
Speaker - |
|
O |
O |
O |
15 |
||
|
P |
O |
O |
16 |
||
|
Q |
O |
O |
17 |
||
|
12v |
R |
O |
O |
18 |
12v |
|
5v |
S |
O |
O |
19 |
5v |
|
5v |
T |
O |
O |
20 |
5v |
|
GND |
U |
O |
O |
21 |
GND |
|
GND |
V |
O |
O |
22 |
GND |
|
Parts |
|
|
|
|
Solder |
|
GND |
A |
O |
O |
1 |
GND |
|
GND |
B |
O |
O |
2 |
GND |
|
5v |
C |
O |
O |
3 |
5v |
|
|
D |
O |
O |
4 |
|
|
|
E |
O |
O |
5 |
|
|
Coin 1 |
F |
O |
O |
6 |
Coin 2 |
|
Player 2 - Down |
G |
O |
O |
7 |
Player 2 - Left |
|
Player 2 - Up |
H |
O |
O |
8 |
Player 2 - Right |
|
Player 1 - Down |
I |
O |
O |
9 |
Player 1 - Left |
|
Player 1 - Up |
J |
O |
O |
10 |
Player 1 - Right |
|
|
K |
O |
O |
11 |
|
|
Player 1 - Button 2 |
L |
O |
O |
12 |
Player 2 - Button 2 |
|
Player 1 - Button 1 |
M |
O |
O |
13 |
Player 2 - Button 1 |
|
Start 1 |
N |
O |
O |
14 |
Start 2 |
|
Sync |
O |
O |
O |
15 |
Video Ground |
|
Red |
P |
O |
O |
16 |
|
|
Blue |
Q |
O |
O |
17 |
Green |
|
Speaker + |
R |
O |
O |
18 |
Speaker - |
|
12v |
S |
O |
O |
19 |
12v |
|
5v |
T |
O |
O |
20 |
5v |
|
GND |
U |
O |
O |
21 |
GND |
|
GND |
V |
O |
O |
22 |
GND |
